1,5-Diisocyanatonaphthalene

enlarge

Systematic / IUPAC Name: 1,5-Diisocyanatonaphthalene

ID: Reference7385

Other Names: Isocyanic acid, 1,5-naphthylene ester;
1,5-Naphthalene diisocyanate;
1,5-Naphthyl diisocyanate;
1,5-Naphthylene diisocyanate;
Naphthalene, 1,5-diisocyanato-

Formula: C12H6N2O2

Class: Extractables/Leachables

Spectral Data

1,5-Diisocyanatonaphthalene mass spectral data can be found in a separate interface. The data are manually curated and of the highest quality.

View Mass Spectra

Available MS Data

Used Instruments Orbitrap Fusion Lumos with ETD LBP FAIMS
No. of Spectral Trees 1
No. of Spectra 162
Tandem Spectra MS1, MS2
Ionization Methods NSI
Analyzers FT
Last Modification 3/28/2018 10:11:41 AM
View Mass Spec Data > >

Identificators

InChI InChI=1S/C12H6N2O2/c15-7-13-11-5-1-3-9-10(11)4-2-6-12(9)14-8-16/h1-6H
InChI Key SBJCUZQNHOLYMD-UHFFFAOYSA-N
Canonical SMILES C1=CC2=C(C=CC=C2N=C=O)C(=C1)N=C=O
CAS 3173726
Splash
Other Names Isocyanic acid, 1,5-naphthylene ester;
1,5-Naphthalene diisocyanate;
1,5-Naphthyl diisocyanate;
1,5-Naphthylene diisocyanate;
Naphthalene, 1,5-diisocyanato-;
Naphthalene-1,5-diisocyanate

In Other Databases

ChemSpider 17476
PubChem 18503
ChEBI CHEBI:82496
KEGG C19464
ChemIDPlus 003173726
