Ethyl 4-[5-amino-4-(ethoxycarbonyl)-1H-pyrazol-1-yl]-5,8-dihydropyrido[4',3':4,5]thieno[2,3-d]pyrimidine-7(6H)-carboxylate
7020
Reference
Ethyl 4-[5-amino-4-(ethoxycarbonyl)-1H-pyrazol-1-yl]-5,8-dihydropyrido[4',3':4,5]thieno[2,3-d]pyrimidine-7(6H)-carboxylate Structure
Systematic / IUPAC Name: Ethyl 4-[5-amino-4-(ethoxycarbonyl)-1H-pyrazol-1-yl]-5,8-dihydropyrido[4',3':4,5]thieno[2,3-d]pyrimidine-7(6H)-carboxylate
ID: Reference7020
Other Names: Pyrido[4',3':4,5]thieno[2,3-d]pyrimidine-7(6H)-carboxylic acid, 4-[5-amino-4-(ethoxycarbonyl)-1H-pyrazol-1-yl]-5,8-dihydro-, ethyl ester
Formula: C18H20N6O4S
Spectral Data
Ethyl 4-[5-amino-4-(ethoxycarbonyl)-1H-pyrazol-1-yl]-5,8-dihydropyrido[4',3':4,5]thieno[2,3-d]pyrimidine-7(6H)-carboxylate mass spectral data can be found in a separate interface. The data are manually curated and of the highest quality.
Available MS Data
| Used Instruments | Q Exactive Orbitrap |
| No. of Spectral Trees | 1 |
| No. of Spectra | 118 |
| Tandem Spectra | MS1, MS2 |
| Ionization Methods | ESI |
| Analyzers | FT |
| Last Modification | 11/21/2017 9:13:21 AM |
Identificators
| InChI | InChI=1S/C18H20N6O4S/c1-3-27-17(25)11-7-22-24(14(11)19)15-13-10-5-6-23(18(26)28-4-2)8-12(10)29-16(13)21-9-20-15/h7,9H,3-6,8,19H2,1-2H3 |
| InChI Key | MFUGPLXFJQVPDZ-UHFFFAOYSA-N |
| Canonical SMILES | CCOC(=O)C1=C(N(N=C1)C2=C3C4=C(CN(CC4)C(=O)OCC)SC3=NC=N2)N |
| CAS | |
| Splash | |
| Other Names | Pyrido[4',3':4,5]thieno[2,3-d]pyrimidine-7(6H)-carboxylic acid, 4-[5-amino-4-(ethoxycarbonyl)-1H-pyrazol-1-yl]-5,8-dihydro-, ethyl ester |
