4-({2-[(3-Oxo-1-phenylbut-1-enyl)amino]ethyl}amino)-4-phenylbut-3-en-2-one

enlarge

Systematic / IUPAC Name: (3Z,3'Z)-4,4'-(1,2-Ethanediyldiimino)bis(4-phenyl-3-buten-2-one)

ID: Reference6426

Other Names: 3-Buten-2-one, 4,4'-(1,2-ethanediyldiimino)bis[4-phenyl-, (3Z,3'Z)-

Formula: C22H24N2O2

Spectral Data

4-({2-[(3-Oxo-1-phenylbut-1-enyl)amino]ethyl}amino)-4-phenylbut-3-en-2-one mass spectral data can be found in a separate interface. The data are manually curated and of the highest quality.

View Mass Spectra

Available MS Data

Used Instruments Q Exactive Orbitrap
No. of Spectral Trees 1
No. of Spectra 119
Tandem Spectra MS1, MS2
Ionization Methods ESI
Analyzers FT
Last Modification 3/2/2017 11:13:09 AM
View Mass Spec Data > >

Identificators

InChI InChI=1S/C22H24N2O2/c1-17(25)15-21(19-9-5-3-6-10-19)23-13-14-24-22(16-18(2)26)20-11-7-4-8-12-20/h3-12,15-16,23-24H,13-14H2,1-2H3/b21-15-,22-16-
InChI Key LXBQYLOHQJTPRY-BMJUYKDLSA-N
Canonical SMILES CC(=O)C=C(C1=CC=CC=C1)NCCNC(=CC(=O)C)C2=CC=CC=C2
CAS
Splash
Other Names 3-Buten-2-one, 4,4'-(1,2-ethanediyldiimino)bis[4-phenyl-, (3Z,3'Z)-

In Other Databases

ChemSpider 4904925
PubChem 6385403
