Ethyl 2-{[(ethoxycarbonyl)amino]carbonyl}-3-[(2-thienylmethyl)amino]acrylate

enlarge

Systematic / IUPAC Name: Ethyl (2Z)-2-[(ethoxycarbonyl)carbamoyl]-3-[(2-thienylmethyl)amino]acrylate

ID: Reference6389

Other Names: 2-Propenoic acid, 2-{[(ethoxycarbonyl)amino]carbonyl}-3-[(2-thienylmethyl)amino]-, ethyl ester, (2Z)-

Formula: C14H18N2O5S

Spectral Data

Ethyl 2-{[(ethoxycarbonyl)amino]carbonyl}-3-[(2-thienylmethyl)amino]acrylate mass spectral data can be found in a separate interface. The data are manually curated and of the highest quality.

View Mass Spectra

Available MS Data

Used Instruments Q Exactive Orbitrap
No. of Spectral Trees 1
No. of Spectra 119
Tandem Spectra MS1, MS2
Ionization Methods ESI
Analyzers FT
Last Modification 2/28/2017 8:11:22 AM
View Mass Spec Data > >

Identificators

InChI InChI=1S/C14H18N2O5S/c1-3-20-13(18)11(12(17)16-14(19)21-4-2)9-15-8-10-6-5-7-22-10/h5-7,9,15H,3-4,8H2,1-2H3,(H,16,17,19)/b11-9-
InChI Key XAZGMMONDHDTKZ-LUAWRHEFSA-N
Canonical SMILES CCOC(=O)C(=CNCC1=CC=CS1)C(=O)NC(=O)OCC
CAS
Splash
Other Names 2-Propenoic acid, 2-{[(ethoxycarbonyl)amino]carbonyl}-3-[(2-thienylmethyl)amino]-, ethyl ester, (2Z)-

In Other Databases

PubChem 2822009
ChemSpider 2100230
