W-19
6069
Reference
W-19 Structure
Systematic / IUPAC Name: N-{(2E)-1-[2-(4-Aminophenyl)ethyl]-2-piperidinylidene}-4-chlorobenzenesulfonamide
ID: Reference6069
Other Names: Benzenesulfonamide, N-{(2E)-1-[2-(4-aminophenyl)ethyl]-2-piperidinylidene}-4-chloro-
Formula: C19H22ClN3O2S
Class: Drugs of Abuse/Illegal Drugs
Spectral Data
W-19 mass spectral data can be found in a separate interface. The data are manually curated and of the highest quality.
Available MS Data
| Used Instruments | Q Exactive Plus Orbitrap |
| No. of Spectral Trees | 1 |
| No. of Spectra | 119 |
| Tandem Spectra | MS1, MS2 |
| Ionization Methods | ESI |
| Analyzers | FT |
| Last Modification | 11/23/2016 7:59:23 AM |
Identificators
| InChI | InChI=1S/C19H22ClN3O2S/c20-16-6-10-18(11-7-16)26(24,25)22-19-3-1-2-13-23(19)14-12-15-4-8-17(21)9-5-15/h4-11H,1-3,12-14,21H2/b22-19+ |
| InChI Key | LPAZQXGIOLCCTG-ZBJSNUHESA-N |
| Canonical SMILES | C1CCN(C(=NS(=O)(=O)C2=CC=C(C=C2)Cl)C1)CCC3=CC=C(C=C3)N |
| CAS | |
| Splash | |
| Other Names | Benzenesulfonamide, N-{(2E)-1-[2-(4-aminophenyl)ethyl]-2-piperidinylidene}-4-chloro- |
