Ethyl 3-[2-(diphenylmethylidene)hydrazino]but-2-enoate

enlarge

Systematic / IUPAC Name: Ethyl (2E)-3-[2-(diphenylmethylene)hydrazino]-2-butenoate

ID: Reference4551

Other Names: Ethyl (2E)-3-[2-(diphenylmethylidene)hydrazinyl]but-2-enoate;
2-Butenoic acid, 3-[2-(diphenylmethylene)hydrazinyl]-, ethyl ester, (2E)-

Formula: C19H20N2O2

Spectral Data

Ethyl 3-[2-(diphenylmethylidene)hydrazino]but-2-enoate mass spectral data can be found in a separate interface. The data are manually curated and of the highest quality.

View Mass Spectra

Available MS Data

Used Instruments Q Exactive Orbitrap
No. of Spectral Trees 1
No. of Spectra 117
Tandem Spectra MS1, MS2
Ionization Methods ESI
Analyzers FT
Last Modification 4/14/2016 10:46:35 AM
View Mass Spec Data > >

Identificators

InChI InChI=1S/C19H20N2O2/c1-3-23-18(22)14-15(2)20-21-19(16-10-6-4-7-11-16)17-12-8-5-9-13-17/h4-14,20H,3H2,1-2H3/b15-14+
InChI Key YWPZHGWESJVRTM-CCEZHUSRSA-N
Canonical SMILES CCOC(=O)C=C(C)NN=C(C1=CC=CC=C1)C2=CC=CC=C2
CAS
Splash
Other Names Ethyl (2E)-3-[2-(diphenylmethylidene)hydrazinyl]but-2-enoate;
2-Butenoic acid, 3-[2-(diphenylmethylene)hydrazinyl]-, ethyl ester, (2E)-

In Other Databases

ChemSpider 4727376
PubChem 5865145
