Ethyl 2-cyano-2-[4-(hydroxymethyl)-5-phenyl-1,3-oxazolan-2-yliden]acetate

enlarge

Systematic / IUPAC Name: Ethyl (2E)-cyano[4-(hydroxymethyl)-5-phenyl-1,3-oxazolidin-2-ylidene]acetate

ID: Reference3532

Other Names: Acetic acid, 2-cyano-2-[4-(hydroxymethyl)-5-phenyl-2-oxazolidinylidene]-, ethyl ester, (2E)-

Formula: C15H16N2O4

Spectral Data

Ethyl 2-cyano-2-[4-(hydroxymethyl)-5-phenyl-1,3-oxazolan-2-yliden]acetate mass spectral data can be found in a separate interface. The data are manually curated and of the highest quality.

View Mass Spectra

Available MS Data

Used Instruments Orbitrap Elite; Q Exactive Orbitrap
No. of Spectral Trees 3
No. of Spectra 4137
Tandem Spectra MS1, MS2, MS3, MS4
Ionization Methods ESI; NSI
Analyzers IT; FT
Last Modification 1/11/2016 10:24:29 AM
View Mass Spec Data > >

Identificators

InChI InChI=1S/C15H16N2O4/c1-2-20-15(19)11(8-16)14-17-12(9-18)13(21-14)10-6-4-3-5-7-10/h3-7,12-13,17-18H,2,9H2,1H3/b14-11+
InChI Key WCNYFSOZVZDMGZ-SDNWHVSQSA-N
Canonical SMILES CCOC(=O)C(=C1NC(C(O1)C2=CC=CC=C2)CO)C#N
CAS
Splash
Other Names Acetic acid, 2-cyano-2-[4-(hydroxymethyl)-5-phenyl-2-oxazolidinylidene]-, ethyl ester, (2E)-

In Other Databases

PubChem 2825726
ChemSpider 2103857
