Diethyl maleate

enlarge

Systematic / IUPAC Name: Diethyl (Z)-but-2-enedioate

ID: Reference2721

Other Names: (Z)-2-Butenedioic acid diethyl ester;
1,4-Diethyl (2Z)-but-2-enedioate;
2-Butenedioic acid (Z)-, diethyl ester;
2-Butenedioic acid (2Z)-, diethyl ester;
2-Butenedioic acid, diethyl ester, (Z)- ; more

Formula: C8H12O4

Class: Extractables/Leachables Industrial Chemicals Textile Chemicals/Auxiliary/Dyes Personal Care Products/Cosmetics Therapeutics/Prescription Drugs Endogenous Metabolites

Spectral Data

Diethyl maleate mass spectral data can be found in a separate interface. The data are manually curated and of the highest quality.

View Mass Spectra

Available MS Data

Used Instruments Orbitrap Fusion Lumos with ETD LBP ; Q Exactive Orbitrap
No. of Spectral Trees 2
No. of Spectra 407
Tandem Spectra MS1, MS2, MS3, MS4
Ionization Methods ESI; NSI
Analyzers FT
Last Modification 4/24/2017 11:37:45 AM
View Mass Spec Data > >

Identificators

InChI InChI=1S/C8H12O4/c1-3-11-7(9)5-6-8(10)12-4-2/h5-6H,3-4H2,1-2H3/b6-5-
InChI Key IEPRKVQEAMIZSS-WAYWQWQTSA-N
Canonical SMILES CCOC(=O)C=CC(=O)OCC
CAS 141059
Splash
Other Names (Z)-2-Butenedioic acid diethyl ester;
1,4-Diethyl (2Z)-but-2-enedioate;
2-Butenedioic acid (Z)-, diethyl ester;
2-Butenedioic acid (2Z)-, diethyl ester;
2-Butenedioic acid, diethyl ester, (Z)-;
2-Butenedioic acid, diethyl ester, (2Z)-;
Diethyl (2Z)but-2-ene-1,4-dioate;
Diethyl (2Z)-but-2-enedioate;
Maleic acid diethyl ester

In Other Databases

ChemSpider 4436353
HMDb HMDB38601
PubChem 5271566
ChemIDPlus 000141059; 068988249; 071342751
ChEBI CHEBI:68508
